Small capacity full-function lubricating oil vacuum purifier 600L/H

Small capacity full-function lubricating oil vacuum purifier 600L/H
Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H Small capacity full-function lubricating oil vacuum purifier 600L/H
Basic Information
Place of Origin: China
Brand Name: Sino-NSH
Certification: CE, ISO, CCC, SGS, CNAS, CQC
Model Number: LV-10
Minimum Order Quantity: 1 set
Price: USD 5000-20000 dollar
Packaging Details: Strong wooden cases, suitable for long distance sea freight transportation and changing climate, good resistance to moisture and shocks
Delivery Time: 15-25 working days for OEM
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50 sets per month
Get Best Price Contact Now
Voltage: 380v/50hz And As Your Option Flow Rate（L/H）: 600-12000
Power(w): 17-186KW Condition: New
Weight: 600-2400KG (l*w*h)Dimension: According To Machine
After-sales Service Provided: Engineers Available To Service Machinery Overseas Certification: CE ISO,ISO9001,SGS,CE/ ISO,BV
Working Pressure: ≤ 0.3Mpa Warranty: 1 Year
Clearness: ≤ 6NAS Function: Lubricating Oil Purification,Degases And Removes The Impurities,Degassing,Dewaters
Color: Customizable Working Temperature: 40 ～ 80℃
Name: Small Capacity Full-function Lubricating Oil Vacuum Purifier 600L/H Heating Power: 15-180KW

Multifunctional Vacuum Lubrication Oil Purifier – Sino-NSH LV Series




Overview
The Sino-NSH LV Series is a high-performance oil purification system designed to effectively remove dissolved/free water and particulate impurities, restoring lubricating oils to optimal condition. By integrating advanced vacuum dehydration and multi-stage filtration, it ensures superior oil clarity (≤6 NAS) and reduces water content to ≤100 ppm, enhancing oil performance and longevity.





Applications
Ideal for treating industrial oils affected by water ingress, emulsification, or contamination, including:

Hydraulic oil, compressor oil, refrigeration oil

Mechanical oil, heat treatment oil

Diesel/gasoline engine oils

Small capacity full-function lubricating oil vacuum purifier 600L/H 0



Key Features & Benefits
✔ High-Efficiency Vacuum Dehydration – Rapidly removes bulk and trace water.
✔ Multi-Stage Filtration – Eliminates particles (≤5 μm) for NAS ≤6 cleanliness.
✔ Anti-Emulsification Technology – Ensures stable oil-water separation.
✔ User-Friendly & Safe – Four-layer protection system for reliable operation.
✔ Environmentally Optimized – Low energy consumption, minimal maintenance.
✔ Online Operation – Continuous purification without interrupting workflows.





Technical Specifications:

Item Unit LV-10 LV-20 LV-30 LV-50 LV-100 LV-150 LV-200
Flow Rate L/H 600 1200 1800 3000 6000 9000 12000
Vacuum Range MPa -0.065~-0.096
Clearness NAS ≤6
Working Pressure MPa ≤0.3
Water Content PPm ≤100
Temperature Content ℃ 40~80
Impurity Size μm ≤5
Power Supply V 380V/50HZ(or as needed)
Working Noise dB ≤70 ≤75
Heating Power Kw 15 18 30 45 90 120 180
Total Power Kw 17 21 35 50 97 126 186
Pipeline Diameter Mm 25 25 25 32 40 50 65
Net Weight Kg 600 800 900 1150 1500 1700 2400
Lengh Mm 1350 1500 1550 1900 2200 2400 2900
width Mm 1100 1200 1250 1400 1500 1600 1800
height Mm 1700 1750 1800 1800 1850 1900 2000








Additional Oil Purification Solutions
TF Series: Optimized for turbine oil, removing water, sludge, and gases.

GER Series: Regenerates used oils (engine, hydraulic) to near-original quality.

GED Series: Converts waste oil into reusable base oil/diesel.





Why Choose Sino-NSH?
✅ 25+ Years of Expertise – Leading manufacturer of industrial oil purifiers.
✅ Premium Quality & Durability – Robust construction with advanced technology.
✅ Global Support – Dedicated after-sales service & on-site assistance.
✅ Custom Solutions – Tailored systems for specific industry needs.

Small capacity full-function lubricating oil vacuum purifier 600L/H 1
