3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System

3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System
3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System 3000L/H Grey Carbon Steel Turbine Oil Purifier with 12 Months Warranty and Lubrication System
Basic Information
Place of Origin: China
Brand Name: Sino-NSH
Certification: CE, ISO, CCC, SGS, CNAS, CQC
Model Number: TF-50
Minimum Order Quantity: 1 set
Price: USD 5000-20000 dollar
Packaging Details: Strong wooden cases, suitable for long distance sea freight transportation and changing climate, good resistance to moisture and shocks
Delivery Time: 15-25 working days for OEM
Payment Terms: L/C,T/T,Western Union,MoneyGram
Supply Ability: 50 sets per month
Get Best Price Contact Now
Power(w): 34KW Condition: New
Weight: 450 Kg Dimension(l*w*h): 1450*1000*1510 CM
After-sales Service Provided: Engineers Available To Service Machinery Overseas Flow: 3000L/H
Voltage: 380v/50hz,380V Or As Per User's Option Working Pressure: ≤ 0.35Mpha
Warranty: 12 Months Function: This Units Can Extend Turbine Oil Life By Removing Contaminates From Oil, Such As Water, Gas And Particulates, Improve The Oil Properties.
Color: Grey, Customizable Raw Material: Carbon Steel
Working Temperature: -10~80℃ Type: Tubine Oil Filtration
Material: Steel Capacity: 3000 L/H
Heating Method: Electric
Highlight:

Turbine Oil Purifier Lubrication System

,

Turbine Oil Purifier 3000L/H

,

450 kg Grey Turbine Oil Purifier

3000L / H Grey Turbine Oil Purifier 34W Lubrication System
The 3000L/H Grey Turbine Oil Purifier is designed for processing unqualified turbine oil, especially seriously emulsified turbine oil. It efficiently removes water, gas, and impurities to restore oil quality to new oil standards, ensuring safe operation of steam turbine units.
Application

This vacuum oil filter uses special polymer materials combined with vacuum separation technology for online demulsification, dehydration, acid removal, and impurity removal. Ideal for turbine oil, low viscosity lubricating oil, and hydraulic oil processing.

Description

The TF turbine oil purifier series utilizes vacuum evaporation, coacervation, coalescing, and refined purification technologies to rapidly eliminate water, gas, impurities, colloids, and dielectric materials in high vacuum conditions, enabling waste oil reuse.

This system effectively extends oil lifetime and protects turbine machinery by preventing oil deterioration caused by vapor, water, and impurities.

Features
  1. Polymer material medium combining demulsification, dehydration, and impurity removal
  2. Compound stereoscopic flash with efficient dewatering/degassing elements
  3. Precision filtration system with backwashing function and long service life
  4. Efficient electric heating system with low energy consumption
  5. Automatic infrared level control and pressure protection systems
  6. Interlock protection for heater, oil pump, and liquid level control
  7. Online operation capability with steam turbines and water turbines
Key Advantages
  • Dehydration (Degas) System: Triple evaporation area for efficient water/gas removal with optimal flowing distance design.
  • Filtering System: Specialized glass fiber media with variable apertures (1-10µm) and β≥1000 filtration capability.
  • Oil Heating System: Uniform heating (20-80℃) with safety protections against overheating.
  • Control System: Schneider/Siemens components with multiple protection systems.
  • Quality Components: Vacuum pumps, oil pumps, and electrical apparatus from leading manufacturers.
Structure and Appearance
  • Ship-shape chassis-mount structure for leakproof operation
  • Compact, lightweight design for easy mobility
  • Available in mobile or stationary configurations
  • Optional stainless steel materials for corrosion resistance
  • Customizable with imported components for enhanced performance
Working Principle

The system operates based on water/oil boiling point differences. Oil passes through main filtration, heating (40-75°C), and vacuum separation where water evaporates and is condensed. Clean oil then undergoes fine filtration before discharge.

Warranty & Documentation

16-month warranty from shipment date or 12-month from startup. Includes 2 copies of operating/maintenance manuals. Performance guarantees subject to specification limitations.

Technical Specifications
Item Unit TF-30 TF-50 TF-100 TF-150 TF-200
Flow Rate L/H 1800 3000 6000 9000 12000
Vacuum Range MPa －0.06～～－0.096
Working Pressure MPa ≤0.3
Water Ratio PPm ≤ 100
Impurity size µm ≤ 5
Clearness NAS(1638) ≤ 6
Temperature Range ℃ 40--80
Demulsifying Value Μin ＜ 15
Power Supply V ~50Hz 380V(or as needed)
Working Noise dB ≤ 70 ≤ 75 ≤ 75 ≤ 75 ≤ 75
Heating Power Kw 30 36 72 90 120
Total Power Kw 33 39 77 98 128
Inlet/Outlet Diameter Mm DN25 DN32 DN40 DN50 DN65
Net Weight Kg 420 550 750 850 950
Size (L×W×H) Mm 1400×1050×1650 1550×1100×1700 1700×1300×1850 1800×1400×1950 1900×1500×2050
Other Oil Purifier Models
  • TF Series: Turbine oil purification for water, vapor, impurities removal
  • LV Series: Lubrication oil filtration for hydraulic/machine oils
  • GER Series: Used oil regeneration for engine/hydraulic oils
  • GED Series: Waste oil recycling into base/diesel oil
