| Place of Origin: | China |
|---|---|
| Brand Name: | SINO-NSH |
| Certification: | CE, ISO,SGS, SASO, SONCAP |
| Model Number: | PF-50 |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiate |
| Packaging Details: | Wooden Case |
| Delivery Time: | 15 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50 sets per month |
| Total Power: | 1.1kW | Function: | Degassing |
|---|---|---|---|
| Color: | Custom | Power Supply: | Fully Customizable |
| Material: | Stainless Steel/Carbon Steel | Warranty: | 1years |
| After Warranty Service:: | Video Technical Support, Online Support | Product Name: | Double-Stage Vacuum Transformer Oil Purifier |
| High Light: | 1.1kw Degassing Portable Oil Purifier,Two Stage Portable Oil Purifier,Portable Oil Purifier 1800L/H |
||
1.1kw With Digital Flow Meter Degassing Protable Lubrication Oil Purifier
Vacuum Transformer Oil Purifier Working Principle:
1. Vacuum oil purifier is designed according to the boiling point of water and oil. It is composed of vacuum heating tank, fine filter, primary filter, vacuum pump, exhaust oil pump and electrical cabinet.
2. Vacuum pump will air out creating vacuum in the vacuum tank, the oil under the action of atmospheric pressure, oil after entrance pipe into the prefilter to remove larger particles, and then enter the heating tank, after heated to a temperature of 40-75 ℃ of oil into the vacuum tank, oil in water evaporate into water vapor rapidly and continuously in the vacuum pump oil water separator, The water vapor in the separator is cooled and reduced to water before being released.
3. The oil in the vacuum heating tank is discharged into the fine filter by the exhaust pump through the filter element to filter out the particulate impurities. In order to complete the vacuum filter quickly remove impurities in the oil, water, gas, the whole process, so that the clean oil discharged from the exit of the machine.
Our Advantage:
1. High water and gas removal efficiency: the technology adopted is efficient THREE-DIMENSIONAL flash technology.
2. High impurity removal ability: high β value precision filter material, multi-level filtration step by step encryption, remove fine particles in the oil. Filter element large volume, large pollution capacity.
3. Short oil treatment time: two-stage high vacuum and large pumping speed, can quickly remove water vapor in the oil, so that the drying degree of oil, breakdown voltage value, a filtration effect can be greatly improved, shorten the oil treatment period, so as to improve the performance of oil.
4. Good comprehensive performance: the machine has the advantages of low noise, simple operation, long maintenance interval, low energy consumption, small operation cost, high oil filter efficiency.
Our Service:
1. 1 years warranty.
2. Provide customers with all technical drawings and materials of equipment purchased for free.
3. Strictly according to customer needs, provide customers with the best oil treatment solutions, provide good performance products.
4. Long-term preferential supply of spare parts
5. Ensure that the equipment provided with perfect processing technology, perfect testing means, equipment performance is good .
6. Long-term free technical consultation, if there is technical innovation, the supplier for users to buy free product system upgrade.
Where do Contaminants Come from in Oil?
1. External environmental sources
2. Air vent systems that may let in particles and dirt.
3. Internal environmental sources
4. Oxidation that forms acids, resins, etc.
5. Rust and corrosion
6. Leaking coolers
1.1kw Protable Lubrication Oil Purifier Technical Parameters:
| Parameter | Value | |||||||
| PF-30 | PF-50 | PF-80 | PF-100 | PF-125 | PF-150 | PF-200 | ||
| Capacity, liters/hour | 1800 | 3000 | 4800 | 6000 | 7500 | 9000 | 12000 | |
| Total Power, kW | 0.75 | 1.1 | 1.5 | 1.5 | 2.2 | 2.2 | 3 | |
| Power supply | Fully Customizable | |||||||
| Height, m | ≥15 | |||||||
| Inlet Diameter, mm | 25 | 32 | 32 | 40 | 40 | 50 | 50 | |
| Outlet Diameter, mm | 25 | 32 | 32 | 40 | 40 | 50 | 50 | |
| Weight(without trailer), kg | 100 | 115 | 130 | 140 | 165 | 180 | 200 | |
| Processed Oil Spec | Cleaness NAS(1638) | ≤6 | ||||||
| Filtration Fineness, um | ≤5( or 1-5 as needed ) | |||||||
Other Models Oil Purifier:
| TF Series: |
| TF series oil filter is a filtration and dehydration unit with thermal and vacuum processing,it's ideal for filtration and dehydration of turbine oil, this unit can extend turbine oil life by removing contaminates from oil, such as water, gas and particulates, improve the oil properties. |
| LV Series: |
| LV series oil filter is a dehydration and degassing unit with thermal and vacuum processing, it's a multifunctional purifier which can treat various kinds of lubricant oils. |
| FV Series: |
| LV series oil filter is a stainless steel machine with thermal and vacuum processing, it's mainly used to improve the properties of phosphate ester fire-resistent oil in generator set. |
| GER Series: |
| Used oil regeneration system is suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil, and used hydraulic oil, other used lubrication oil of machinery. |
| GED series: |
| it is used to recycle all kinds of waste oil into base oil or diesel oil with high quality. |
