Outdoor Type Vacuum Pump Unit Transformer Evacuating Vacuum Degree 0.05 Pa

Outdoor Type Vacuum Pump Unit Transformer Evacuating Vacuum Degree 0.05 Pa

Functions

VR series vacuum pump unit is composed of a Roots pump (mechanical booster pump) as the main pump and a rotary vane vacuum pump as a fore-stage pump. The unit is mainly used for vacuuming and drying various vacuum systems that require high pumping speed and obtain medium and high vacuum, especially suitable for vacuuming transformers. This vacuum drying and exhaust unit is widely used in vacuum smelting, vacuum heat treatment, welding, chemical pharmaceuticals, vacuum coating, electronic components, and other industries.

Application

• It is mainly used to extract the gas in the container so that the container can reach high vacuum requirements, and can also be used for vacuum drying.
• This unit is particularly suitable for vacuuming transformers in the power industry, and can also be used for vacuuming in vacuum smelting, welding, chemical pharmaceuticals, vacuum coating, electronic components, and other industries.

Advantages

• It has the characteristics of a fast start-up, high pumping speed, stable performance, and easy operation.
• Roots pump is used as the main pump and rotary vane vacuum pump is used as the front pump.
• It is fully automatic and can be operated unmanned. The operating status is displayed by the indicator light.
• The machine is humanized in design, with low noise and low energy consumption to save operating costs.
• Equipped with a pipeline filter, it can effectively prevent larger particles of impurities from entering the system and damaging the vacuum pump.
• It is equipped with a gas circuit check device to prevent gas reflux, vacuum leakage, oil leakage, and other phenomena in the case of abnormal sudden shutdown.
• Imported pumps can quickly obtain a higher working vacuum degree.

Optional Accessories

• Metal enclosure
• Roadworthy trailer
• Hose (comes with 10 meters wire reinforced PVC hose)
• Optional PLC (intelligent programmable logic control system): touch screen HMI operation interface, and dynamic display.
• Imported components. (Optional imported brand vacuum pump group, electrical components, instruments)
• Pirani digital high-precision vacuum gauge.

Optional Appearance

• Base structure: A. Mobile caster wheels type B. Fixed installation type C. Mobile trailer type
• Frame structure: A. Open type B. Roof eaves type C. Fully enclosed rainproof house D. Canvas shed shelter type
• Material selection: A. High carbon steel B. Cast steel
• Color selection: Customizable color

Parameters

5. What You’ll Get After Your Inquiry

1. Formal quotation with price, product and accessories list, and warranty.
2. Technical details including specs sheet, machine detailed introduction, 3D model, flow chart, and reference pictures.
3. Configuration details.
4. Reference videos.

Delivery

1. Wooden case
2. Factory inspection.
3. FOB, CIF, EXW, etc price terms available.
4. 10-20 working days prepared at our factory.
5. 12-month warranty and lifelong after-sale services.
6. Manual book with structure diagram, operation, and maintenance instructions.
7. Instruction Video.

Pictures

Related Equipment

• Vacuum transformer oil purifier
• Dry air generator
• SF6 gas recycling and charging device
• Breakdown voltage tester
