Dehydration Multifunctional turbine lube oil system 3000L/H

Dehydration Multifunctional turbine lube oil system 3000L/H
Dehydration Multifunctional turbine lube oil system 3000L/H Dehydration Multifunctional turbine lube oil system 3000L/H Dehydration Multifunctional turbine lube oil system 3000L/H
Basic Information
Place of Origin: China
Brand Name: SINO-NSH
Certification: CE, ISO,SGS, SASO, SONCAP
Model Number: LV-50
Minimum Order Quantity: 1 Set
Price: Negotiate
Packaging Details: Wooden Case
Delivery Time: 15 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50 sets per month
Get Best Price Contact Now
Total Power: 50kW Capacity: 3000L/H
Color: Custom Power Supply: Fully Customizable
Material: Stainless Steel/Carbon Steel Warranty: 1years
After Warranty Service:: Video Technical Support, Online Support Product Name: Double-Stage Vacuum Transformer Oil Purifier
Highlight:

Multifunctional Turbine Lube Oil System

,

Dehydration Turbine Lube Oil System

,

Turbine Lube Oil System 3000L/H

High Volume 3000L/H Dehydration Multifunctional Vacuum Lubrication Oil Purifier





What is Oil Purifier?


Oil filter is a filter device which uses gravity centrifugal pressure vacuum distillation mass transfer and other technical methods to remove the oxidation by-products and moisture of mechanical impurities in impure oil. Oil filter is mainly used to improve the cleanliness of mechanical and electric





Vacuum Lubrication Oil Purifier Description:



1. Sino-NSH-LV is a dehydration and degassing unit with thermal and vacuum processing. It is a multifuncational purifier which can treat various kinds of lubricant oils.
2. Sino-NSH-LV is mainly used to remove dissolved and fee water,and particulate impurities effectively so as to increase special indexes of lubricant oil. Combining with vacuum system, the multi-stage filtration system adopts a high dehydration efficiency,it has a strong anti-emulsifying capability, which could separate the large amount of water from oil and trace water from oil. The clearness of final oil can be under 6 NAS and water can be under 100PPM after processing with our machine.
3. Sino-NSH-LV maintains an optimized structure and safe controls so as to meet comprehensive requirements of transformer manufacturers and service companies.

Dehydration Multifunctional turbine lube oil system 3000L/H 0





Vacuum Lubrication Oil Purifier Technical Parameters:



Parameter Value
LV-10 LV-20 LV-30 LV-50 LV-100 LV-150 LV-200
Capacity, liters/hour 600 1200 1800 3000 6000 9000 12000
Heating Power, kW 15 18 30 45 90 120 180
Total Power, kW 17 21 35 50 96 126 186
Power supply Fully Customizable
Inlet Diameter, mm 20 20 20 25 40 50 65
Outlet Diameter, mm 20 20 20 25 40 50 65
Dimensions
(without trailer)		 length, mm 1350 1500 1550 1900 2200 2400 2900
width, mm 1100 1200 1250 1400 1500 1600 1800
height, mm 1700 1750 1800 1800 1850 1900 2000
Weight(without trailer), kg 600 800 900 1150 1500 1700 2400
Processed Oil Spec Water Content, ppm ≤100
Dielectric Strength, Kv ≤6
Filtration Fineness, um ≤5( or 1-5 as needed )





Corollary Equipment-VR Vacuum Pump Set:


SINO-NSH-VR is units create vacuum in transformer and other equipment with double-stage vacuum system.

Parameter Value
VR-30 VR-70 VR-150 VR-300 VR-600 VR-900
Capacity, liters/hour 100 250 500 1000 2000 3000
Total Power, kW 3 3 5 7 8 13
Power supply Fully Customizable
Maximum Vacuum Range,Pa 0.06
Outlet Diameter, mm 32 32 40 40 50 65
Dimensions length, mm 900 550 1000 1200 1500 1950
width, mm 800 900 800 800 1000 1800
height, mm 1200 800 1200 1200 1200 1300
Weight(without trailer), kg 450 550 600 900 950 1950





Our Service:


1. 1 years warranty.
2. Provide customers with all technical drawings and materials of equipment purchased for free.
3. Strictly according to customer needs, provide customers with the best oil treatment solutions, provide good performance products.
4. Long-term preferential supply of spare parts
5. Ensure that the equipment provided with perfect processing technology, perfect testing means, equipment performance is good .
6. Long-term free technical consultation, if there is technical innovation, the supplier for users to buy free product system upgrade.

Dehydration Multifunctional turbine lube oil system 3000L/H 1

Dehydration Multifunctional turbine lube oil system 3000L/H 2
