Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content

Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content
Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content
Basic Information
Place of Origin: China
Brand Name: Sino-NSH
Certification: CE,ISO,SGS,SASO
Model Number: VFD
Minimum Order Quantity: 1 Set
Packaging Details: Strong wooden cases, suitable for long distance sea freight transportation and changing climate, good resistance to moisture and shocks
Delivery Time: 10 working days
Payment Terms: L/C,T/T
Supply Ability: 30 sets per month
Get Best Price Contact Now
Condition: Brand New Product Name: Transformer Oil Filter Machine
Function: Dehydration, Degassing, Remove Impurities Flow Rate: 1800 ~18000 Liters/Hour
Filtration Precision: ≤1μm Water Content: ≤3 PPM
Gas Content: ≤0.1% Temperature: 20~80℃
Power Supply: 380V/3P/50Hz(or As Needed) Service: Engineers Available To Service Machinery Overseas
Color: Green,Blue,green And Gray,Customizable,yellow.
Highlight:

Degassing Transformer Oil Filtration Machine

,

Remove Impurities Oil Filtration Machine

,

Coarse Transformer Oil Filtration Machine

Transformer Electric Oil Filtration Recycling Equipment

Professional transformer oil filter machine designed for power transformer oils purification and recycling.

Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content 0 Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content 1
Application

NSH VFD insulation Oil Purifier equipment is primarily used to enhance the properties of insulation oil. It effectively removes trace water, gas, and particulate matter from insulating oil, transformer oil, and electric oil, improving the performance of transformers, circuit breakers, mutual inductors, cables, and capacitors with insulation systems.

Key Benefits
  • Low maintenance and replacement costs
  • High-performance security system with pressure protection and automatic temperature control
  • Advanced coacervation, coalescing, separating, and refined purification technologies
  • Effective removal of free/soluble water, carbon, gases, and particulate matter
  • Can operate independently or with oil regeneration system to eliminate acid and improve PH value
  • Includes automatic breakdown voltage tester for transformer oil
Working Process
  1. Oil passes through coarse filter to remove large particles
  2. Electric heater uniformly heats the oil
  3. Special vacuum tank maximizes dehydration and degassing
  4. Oil passes through fine filter after vacuum treatment
  5. Oil circulation recommended for optimal purification
Post-Filtration Oil Quality
Parameter Unit Value
Dielectric Strength (BDV) Kv ≥ 75
Water Content PPM ≤ 3
Gas Content % ≤0.1
Impurity Size μm ≤1
Dielectric Loss Tg ≤0.005
Interfacial Tension mn/m ≥40
Technical Specifications
Item Unit VFD-30 VFD-50 VFD-80 VFD-100 VFD-150 VFD-200 VFD-300
Flow Rate L/H 1800 3000 4800 6000 9000 12000 18000
Vacuum Range Mpa -0.092 ～ -0.099
Working Pressure Mpa ≤0.2
Max Vacuum Range Pa ≤50
Temperature Range ℃ 20 ～ 80
Power Supply 380V/3P/50Hz(or as needed)
Working Noise dB(A) ≤72 ≤78 ≤78 ≤78 ≤78 ≤78 ≤78
Heating Power Kw 24 30 48 60 90 120 150
Total Power Kw 29 36 56 69 100 132 170
Pipeline Diameter mm DN25 DN32 DN32 DN40 DN40 DN50 DN65
Net Weight Kg 600 800 900 1150 1500 1700 2400
Size (L×W×H) mm 1350×1100×1700 1500×1200×1750 1550×1250×1800 1900×1400×1800 2200×1500×1850 2400×1600×1900 2900×1800×2000
Available Configurations
  • Fixing type, mobile type with four wheels, or mobile type with trailer
  • Standard appearance, shelf-covering type, or explosion-proof type
  • Available in different colors
Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content 2 Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content 3 Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content 4 Transformer Oil Filtration Machine with 1800 ~18000 Liters/Hour Flow Rate, ≤1μm Filtration Precision, and ≤3 PPM Water Content 5
About Our Company

We are a leading manufacturer with over thirty years of experience, providing high-quality, cost-effective oil purification equipment. Our dielectric oil purification systems are crafted from premium materials using advanced technology by skilled technicians.

We stand behind every product with integrity and excellent after-sales service. Our team is always available to address your needs before or after purchase.

With extensive industry experience, we can provide solutions for any on-site challenges. Contact us for detailed product specifications or to request our catalog.
