Mobile Transformer Oil Filtration Machine High Vacuum Pressure For Power Transformer Oils

Transformer Oil Filtration and Dehydration Plant for High Voltage Power Transformer,

Used Transformer Oil Filter Machine



I. Application of Transformer Oil Filtration Machine

Due to the highly hygroscopic nature of the transformer oil, it absorbs moisture from windings, which leads to gradual deterioration of dielectric strength. Also there are some waste impurities, gas contents in the transformer oil which destroy the oil’s quality.

Vacuum Transformer Oil Filtration Machine (Series VFD) is especially designed for on site use to completely regenerate insulating oils in energized or de-energized transformers even when transformer power both below and above 110KV and altitude over 500 meters, as well as purify mutual inductor oil, switch oil and so on. Also it can inject the insulating oil into the transformers on-line and dry the transformer.

II. Features of Transformer Oil Filtration Machine

1. Double-stage, high vacuum pressure and high flow rate.

2. Adopts Duplex 3D stereo-evaporation & flash distillation technique, eliminating the liquid water & gas content quickly.

3. Low maintenance cost and time, simple operation and maintenances.

4. Trace water such as dissolved water, can be removed effectively.

5. Distinctive removing impurities system filtering through double FH trapezoidal network and absorbing by high polymer without the mechanical power. Precise fine multi-stage filtration for removal of solids, water and gasses

6. Carbon fiber infrared heating system that can make the oil contains zero sum of ethyne after the treatment

7. Especially applied to vacuum oil injection and drying (Hot Oil Circulation / on-site Drying) for power transmission equipments which are over 110KV

8. Contains Transformer Evacuation System

9. Advanced dielectric Condenser devices, Automatic pressure protection, automatic constant temperature control, automatic oil level control

10. This Oil purifier can be made in mobile type with trailer, hermetical, canopy-covering, open and frame style

11. Can be operated both on-load and off-load, PLC making machine run fully automatically is optional.

III. Oil Data Before & After Oil Filtration

IV.Machine Specification of Transformer Oil Filtration Machine

V. Available Style of Transformer Oil Filtration Machine
1. Fixing type,mobile type with four wheels and mobile type with trailer.
2. Normal appearance type,shelf-covering type and explosion-proof type.
3. Avaliable in different color.
