CPA-1000 Disc Centrifugal Oil Separator | 1000 L/H Fuel & Lube Oil Purifier

Basic Information

Place of Origin:	CHINA
Brand Name:	Sino-NSH
Certification:	ISO,CE
Model Number:	CP CPA CPPA

Minimum Order Quantity:	1 Set
Packaging Details:	Strong wooden cases, suitable for long distance sea freight transportation and changing climate, good resistance to moisture and shocks
Delivery Time:	10 working days
Supply Ability:	50 sets per month

Get Best Price Contact Now

Application:	Oil Purifier,oil Purification,oil Fitraion,oil Treatment,oil Recycling,oil Regeneration	Function:	Dehydration, Degassing, Remove Impurities
Flow Rate:	1000-100000L/H	Power Supply:	380V/3P/50Hz(or As Needed)
After-sales Service Provided:	Engineers Available To Service Machinery Overseas	Color:	As Your Requirement
Product Name:	Insulation Oil Purifier	Usage:	Transformer Oil, Lubricant Oil, Insulation Oil, Oil Filtration,Edible Oil
Highlight:	Fuel Oil Centrifugal Separators , CPA Centrifugal Separators , 1000L/H Centrifugal Separators

High-speed disc centrifuge for removing water, sludge and fine solids from diesel fuel, marine fuel and lubricating oil.

The Disc Centrifugal Separator series is especially designed for the oil industry for the purification and recycling of liquid oil. This series is designed to overcome the harmful effects of oil contaminants, water and solid particles from fuel oil, lubricating oil and other mineral oil in marine engine unit and land generator unit of power station so as to reduce wear of diesel engine and other machine, and prolong the serving life. The model is also used to separate two unsolvable liquids with different specific gravity or remove small amount of solid particle from liquid.

NSH provides the whole solution for your project.

NSH Separators adopts:

Easy-handling control
High separation efficiency
Unattended operation available
Low consumption
Economic maintenance cost
High speed rotary machine, low vibration, safe and stable

Basic Design Includes

Feed pump
Centrifugal separator
Discharge pump
Control panel
Primary filter
Fine filter
Heating system
Instrumentation
Protection controlling system
Base frame with drip pan, lifting lugs and skid caster
Heavy duty suitable painting

N O	Capacity (L/h)				Available Heating Mode (steam as option)		Available Operation Mode		Discharge Mode		PLC (Option)
N O	Fuel oil	180CST Fuel oil	380CST Fuel oil	SAE30/40 Lube oil	Electric	External Steam	Manual Auto		Manual Auto		PLC (Option)
1	1600			800	√	*	√		√		√
2	4000			2000	√	*	√		√		√
3	1700	800	600	800	√	*	√	√	√	√	√
4	2200	1000	800	1000	√	*	√	√	√	√	√
5	3000	1500	1200	1500	√	*	√	√	√	√	√
6	3500	2000	1500	2000	√	*	√	√	√	√	√
7	4200	2300	1800	2300	√	*	√	√	√	√	√
8	5500	3000	2300	3000	√	*	√	√	√	√	√
9	8000	4500	3000	4000	√	*	√	√	√	√	√
10	12000	6000	4000	5000	√	*	√	√	√	√	√

Customer Situation	Recommended Solution
High water content in diesel or fuel oil	Disc centrifugal separator
Large amount of sludge and fine solids	Disc centrifugal separator
Continuous operation for marine engine or generator	Disc centrifugal separator
Transformer oil dehydration and degassing	Vacuum oil purifier
Fine polishing after centrifugal separation	Fine filtration system

Not sure whether centrifugal separation is suitable for your oil? Send us your oil type, viscosity and contamination condition. Our engineer will recommend the right configuration.

Can CPA-1000 remove emulsified water?

CPA-1000 can remove free water and part of emulsified water. The final performance depends on oil type, viscosity, temperature and contamination condition. Please send oil sample data for confirmation.

Is heating necessary?

Heating is recommended for high-viscosity fuel oil and lubricating oil to improve separation efficiency.

Can the separator run continuously?

Yes. The system can be configured for continuous operation. PLC control and automatic sludge discharge are available as options.

What information is needed for quotation?

Please provide oil type, viscosity, required capacity, water content, solid contamination level, power supply and installation location.

How long is the delivery time?

Standard models can be prepared quickly; final delivery time depends on configuration and optional accessories.
